Creamsource Vortex4 | 1’ × 1’ Colour LED Panel

Overview

The Creamsource Vortex4 is a high-output 1 × 1 full colour LED panel designed for film, TV and commercial production. Available for hire in London, it combines punchy output, advanced colour control and rugged IP65 construction, making it suitable for studio work, location lighting and demanding exterior environments.

Key Features

• Full Colour RGBW Engine – Delivers accurate white light and a wide range of creative colour options.
• Punchy 1×1 Output – Compact panel format with a native 20° beam for hard punch or use through diffusion.
• Wide CCT Range – Adjustable from 2200K to 15,000K for matching daylight, tungsten and mixed lighting environments.
• IP65 Weatherproof Construction – Fully weather-sealed design suitable for demanding exterior production environments.
• Professional Control – DMX, CRMX / LumenRadio, Ethernet, Bluetooth and WiFi control for advanced lighting workflows.
• Integrated Power Supply – All-in-one fixture with built-in PSU and antennas for cleaner rigging.
• Production-Ready Design – Robust construction designed for high-end film, television and commercial production.

Typical Uses

• Punchy hard or soft source
• Through diffusion or bounce
• Compact colour effects light
• Studio and location production
• Film, TV and commercial lighting

Creamsource Vortex4 Specifications

Output, dimensions, weight and control specifications.

• Output: approx 7,300 lux @3m / 29,100 lumens
• CCT Range: 🔴🟢🔵 2200K–15,000K
• CRI / TLCI: ≥95
• Power Draw: 325W
• Colour: Full Colour RGBW / RRGBBW
• Control: DMX / CRMX / Ethernet / Bluetooth / WiFi
• Dimming: 0–100% flicker-free
• Weight: ⚖️ approx 9.9kg excluding yoke
• Dimensions: 380 × 380 × 121mm / 1×1 Panel
• Weather Rating: 🚿 IP65 Weatherproof
