ARRI SkyPanel X | 2’ × 1’ Full Colour LED Panel

Overview

The ARRI SkyPanel X is a high-output full colour LED panel designed for film, TV and commercial production. Available for hire in London, it combines ARRI's advanced RGBACL colour engine, exceptional white light quality and weatherproof construction, making it suitable for studio work, location lighting and demanding exterior environments.

Key Features

• RGBACL Colour Engine – Advanced six-colour light engine delivering exceptional colour accuracy, natural skin tones and highly saturated colours.
• High Output Performance – Powerful output suitable for key lighting, bounce, diffusion and large-scale lighting setups.
• Wide CCT Range – Adjustable from 1,500K to 20,000K for matching daylight, tungsten and mixed lighting environments.
• Native Soft Source – Large illuminated surface produces flattering, wrap-around light with minimal shadow contrast.
• Professional Control – DMX, CRMX, Ethernet, Art-Net and sACN compatibility for advanced lighting workflows.
• Weatherproof Construction (IP66) – Fully weather-sealed design suitable for demanding exterior production environments.
• ARRI Production Ecosystem – Designed for seamless integration with modern film and television lighting workflows.

Typical Uses

• Soft key lighting
• Lighting through diffusion
• Large bounce source
• Studio and location production
• Film, TV and commercial lighting

ARRI SkyPanel X Specifications

Output, dimensions, weight and control specifications.

• Output: up to 24,000 lux @3m (open face)
• CCT Range: 🔴🟢🔵 1,500K–20,000K
• CRI / TLCI: ≥95 / ≥95
• Power Draw: 720W
• Colour: Full Colour RGBACL
• Control: DMX / CRMX / Ethernet / Art-Net / sACN
• Dimming: 0–100% flicker-free
• Weight: ⚖️ approx 12kg (head)
• Dimensions: approx 645 × 437 × 103mm
• Weather Rating: 🚿 IP66 Weatherproof

ARRI SkyPanel X Base Kit

⚡ 720W 🔴🟢🔵 Full Colour 🚿 IP66 🎛️ DMX / CRMX

Base kit includes:

• SkyPanel X head
• Power supply
• Power lead
• Yoke
• Controller accessories

£205 per day + VAT (per unit)

Head Sky Panel X21

Included in Base Kit

• Head: ARRI SkyPanel X21
• Mounting: Yoke & Junior Spigot
• Control: All-Weather Control Panel
• Power Lead: 16A → PowerCON
• Dimensions: 74 × 34 × 15.5cm
• Weight: 18kg

Soft Dome Sky Panel X21

Included in Base Kit

• Type: Clip-On Diffusion Dome
• Output: ⚪ Uniform Soft Light
• Compatibility: ARRI SkyPanel X21
• Dimensions: 71 × 32.5 × 7cm
• Weight: 1.8kg*

Hyper Optic Sky Panel X21

• Type: Hyper Optic Lens Attachment
• Output: ☀️ Increased Punch & Throw
• Optics: 72 Individual Lenses Collimated into a Single Oval Beam
• Compatibility: ARRI SkyPanel X21
• Dimensions: 71 × 32 × 10.5cm
• Weight: 4.8kg

Beam Enhancer Sky Panel X21

• Type: Beam Enhancer Diffusion Panel
• Output: ⚪ Softens Hyper Optic Output
• Control: Reduces Beam Artefacts & Improves Uniformity
• Compatibility: ARRI SkyPanel X21
